Proxitron IKZ 122.22 GH

http://www.intl-sensor.com Time:2008/6/10 15:19:06 Count : 61 Times

Type IKZ 122.22 GH
Art.-No. 2265B
Rated operating distance (Sn) 3 mm
Operating distance adjustable no
Output PNP n. c.
Target steel St37, 1 mm thick 12 x 12 mm
Location at metal flush
Supply voltage (UB) 10 - 30 V DC
Ripple voltage < 15 %
Load current max. 120 mA / +100 °C
70 mA / +150 °C
Short circuit protection yes
Voltage drop (Ud) 2 V
Operating frequency (f) 200 Hz
Switching hysteresis (H) max. 15 %
Ambient temperature -25 ... +150 °C
Protection class IP 67
Connection 2 m silicone cable
Function display no
Housing material stainless steel
